Description
Ford F-150 Raptor 17×9 Strike Beadlock Forged Wheels – 6 Lug
Engineered specifically for Ford F-150 Raptors and New Gen Broncos. These are true 1-piece monoblock forged beadlock wheels.
Tire Fitment: Fits up to 13.5″ wide tires. Gen 3 Raptor pictured runs 37×12.5R17 BF Goodrich tires with a 2″ leveling collar. Minor trimming may be required.
Features
- Forged 6061 aluminum construction – lightweight and durable
- Includes billet beadlock ring and beadlock hardware
- Standard billet center caps (floating and custom logo options available)
- Made in California, U.S.A.
Specifications
- Model: Strike
- Size: 17×9″
- Bolt Pattern: 6×135 MM
- Lug Style: Conical Seat
- Weight Rating: 3,500 lbs
- Finish: Custom finish options available
- Beadlock Bolts: M10x1.25 10.9 Grade (ARP 12-point upgrade optional)
Backspace / Offset Options
| Size | Backspace | Offset |
|---|---|---|
| 17×9″ | 4.5″ | -12mm |
| 17×9″ | 5″ | 0mm |
| 17×9″ | 5.75″ | +19mm |
Product Image
Disclaimer: Beadlock wheels are for off-road use only. Max tire pressure is 25 PSI. Check and re-torque hardware regularly. Not for street use, towing, or hauling. VNM Forged / Venum Wheel is not responsible for improper use.
