Description
8×170 Wheel Spacers Adapters Hub Centric Ford Super Duty F-250 F-350
Fully Hub Centric Wheel Spacers
8×170 Wheel Spacers Adapters Billet
Made to Order: This product is made to order and may take up to 7 business days to ship. (2 Inches are in stock – ready to ship)
Sold As: 1 Pc Wheel Spacer Adapter with Mounting Lug Nuts
Complete Set: If you need a complete set, select 4 under quantity.
2023–2026 F-250 / F-350: The rear wheel spacers are supplied without a hub-centric lip. This is only way it will work on the rear, the fronts have a lip.
Features
- Compatible with factory and aftermarket wheels
- Hub/Wheel Centric – no vibration at high speeds
- Corrects improper wheel offsets
- Provides an aggressive stance and improved look
- 6061 T-6 billet aluminum construction
- Designed for extreme duty; safe for towing
- Includes all mounting hardware
- Limited lifetime warranty
- Made in Lynwood, California, USA
Specifications
- Vehicle Bolt Pattern: 8×170 MM
- Vehicle Hub Bore: 125 MM
- Wheel Bolt Pattern: 8×170 MM
- Wheel Bore: 125 MM
- Thread Pitch: 14×1.5 | 14×2
- Thickness: 1″ – 5″
- Lip Thickness: 0.38″
- Material: Billet Aluminum 6061 T-6
- Hardware: Grade 8
- Finish: Raw Aluminum
- Torque Specs: Use factory specs
Vehicle Compatibility
| Year | Make | Model | Thread Pitch |
|---|---|---|---|
| 1999-2002 | Ford | F-250 | 14×2 |
| 1999-2002 | Ford | F-350 | 14×2 |
| 2003-2016 | Ford | F-250 | 14×1.5 |
| 2003-2016 | Ford | F-350 SRW | 14×1.5 |
| 2017-2022 | Ford | F-250 | 14×1.5 |
| 2017-2022 | Ford | F-350 SRW | 14×1.5 |
| 2023-2026 | Ford | F-250 | 14×1.5 |
| 2023-2026 | Ford | F-350 SRW | 14×1.5 |
Frequently Asked Questions
What is the maximum towing capacity?
We’ve tested up to 21,000 lbs on a 2020 Ford F-250 Super Duty (rated for 20,000 lbs). No issues were found. Our spacers will not limit your truck’s towing capacity.
Installation Instructions
- Studs must not extend past the spacer face; trim if needed
- Minimal trimming required for adapters 1.5″ or thinner
- Use factory torque specs when mounting
- Use blue or red Loctite on vehicle stud side
Keywords: 8×170 wheel spacers, wheel adapters, hub centric billet, ford super duty, 8×170 spacers, ford wheel spacers
